Feature:
Multi-folded periphery of the enclosure to avoid water and sundries
entering into the inner enclosure;
Cold rolled steel welded frame with strong structure;
All-round polyurethane gasket in the door with good protection;
Molded door border with exquisite image and strong intensity;
Door can be turned to 110 degrees with hige, and 180 degrees with
special hinge;
Adjustable mounting panel;
M8 earth pole is mounted on the body, door and the mounting panel;
Mounting hole drilled at the back of the enclosure, no need extra holes.
Degree of protection:
Comply with IEC60529, EN60529/10.91 and GB4208-93 standard:
Small size enclosure with IP66(width and height less than 400mm);
Width and height over 400mm enclosure with Ip55;
Material:
SPCC cold rolled steel;
Thickness:mounting panel:2.5MM; others:1.5mm;
Surface finish:
Body of enclosure and doors;
Degreasing, phosphoric, electrophoretic dip-coated printed,
static power with textured stove enamel RAL7035
Mounting panel(SPCC cold rolled steel)
Degreasing, pickling, phosphoric, electrophoretic dip-coated printed,
static powdered with flat coating RAL2000.
Use:
Available for mounting various kinds of electronic componet,
controlling and cable entry.
