Standard:
Comply with ANSI/EIA ARS-310-D,AIEC297-2、DIN41494,
PART1,DIN41494,PART7 standard.
Feature:
Modular design,easily assemble and disassemble for
delivery,low-cost;
Various optional accessories according to requirements
(cable management slot,removable working panel,etc.,).
Loading Capacity:
Static loading: 150KG.
Material:
SPCC cold rolled steel;
Thickness:plinth and front beams: 1.2mm;
Bottom beams and pole 1.5mm;
Surface finish:
Degreasing,phosphoric,powder coated.
