Standard:
Comply with ANSI/EIA RS-310-D,IEC297-2、DIN41491
PART1,DIN41494,PART7 GB/T3047.2-92 standard.
Feature:
Modular design,easily assemble and disassemble for delivery,
low-cost;
19" standard installation,adjustable rack height;
Easy to fix and maintain, stable and strong structure;
Various optional installation according to requirements(cable
management slot,cantilever shelf,wall-mount cabiners etc.,).
Loading Capacity:
Static loading:200KG
Material:
Plith:angle iron,others:SPCC cold rolled steel;
Thickness: plinth: 6.0mm;
Surface finish:
Degreasing,phosphoric,powder coated.
