Standard:
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、
DIN41494;part7,GB/T3047.2-92 standard.

Feature:
Double sction welded frame structure;
Easy operation and maintaining at the back;
19"standard installation;
Removable side panels, side locks are optional, easy
installing and maintaining;
Knock out hole for entering cable on both of top cove
and bottom panel;
120mm fan(optional);
Turning angle of front door is abve 180 degrees;
Turning angle of rear door is above 90 degrees.

Loading Capacity
60KG.

Degree of Protection:
Ip20.

Material:
SPCC Cold Rolled Steel
Thickness: Mounting profile:1.5mm, others:1.2mm.

Surface finish:
Degreasing,phosphoric,powder coated.
