Standard:
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;
PART1、DIN41494;PART7、ETSI standard.

Feature:
Exquiste design with precise dimentsion and craftsmanship;
Hexagonal reticular high-density vented plate front door and
rear door;
Blue Zinc Moungting Profiles,free of static;
Adjustable feet and heavy duty castors are available at the
same time;
Several lockable cable entry on top cover and bottom panel
with adjustable sizes;
Optioanl plinth enables cabinet to stay in a fixed posion,
meeting requirments of under-base cable entry/ventilation
and preventinon;
Efficient cabinet baying kit(patent);
Removable side panels, easy to install and maintain;
Around 1/2~2/3 of original assembled volume when flat pack.

Material:
SPCC cold rolled steel;
Thickness: mounting profile 2.0mm, mounting
angle 1.5mm, others 1.2mm
Surface finish:
Degreasing,phosphoric,powder coated.
Degree of Protection:
Ip20.
Loading Capacity
Static loading:800KG(with adjustable feet).
