Standard:
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、
DIN41494;PART7,ETSI standard.

Feature:
Exquiste design with precise dimentsion and craftsmanship;
Toughened glass front door with silk-screened flower patten, door border and steel rear door;
Blue Zinc Moungting Profiles,free of static;
Adjustable feet and heavy duty castors are available at the same time;
Several lockable cable entry on top cover and bottom panel with adjustable sizes;
Optional plinth enables cabinet to stay in a fixed position, meeting requirements of
Under-base cable entry/ventilation and prevention;
Efficient cabinet baying kit(patent);
Removable side panels,easy to in stall and maintain;
Around 1/2~2/3 of original assembled volume when flast pack.

Material
SPCC cold rolled steel;
Thickness: mounting profile 2.0mm,
mounting angle 1.5mm, others 1.2mm

Surface finish:
Degreasing,phoshporic,powder coated.

Degree of Protection:
Ip20.

Loading Capacity:
Static loading:800KG(with adjustable feet).
