Standard:
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、
DIN41494;PART7,ETSI standard.
Feature:
Exquiste design with precise dimentsion and craftsmanship;
Steet front & rear door without hole;
Blue Zinc Moungting Profiles,free of static;
Adjustable feet and heavy duty castors are available at the same time;
Several lock cable entry on top cover and bottom panel with adjustable sizes;
Optional plinth enables cabinet to stay in a fixed position, meeting
requirementsof under-base cable entry/venilation and prevention;
Efficient cabinet baying kit(patent);
Removable side panels,easy to install and maintain;
Around 1/2~2/3 of original assembled volume when flat pack.
Material:
SPCC cold rolled steel;
Thickness: mounting profile 2.0mm, mounting
andgle 1.5mm, others 1.2mm
Surface finish:
Degreasing,phoshoric,powder coated.
Degree of Protection:
Ip20.
Loading Capacity
Static loading:800KG(with adjustable feet).
