Standard:
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、DIN41494;PART7,ETSI standard.

Feature:
Hexagonal reticular high-density vented front door(patent) & rear door for protection, ventilation and reliable operation;
Exquisite image(patent) with precise dimension and craftsmanship;
Lockable cable entry on top cover and bottom panel with adjustable sizes;
Optional plinth enables cabinets to stay in a fixed position while meetingrequirements of under-base wiring/ventilation and rat prevention;
Strong cablinet connection by baying kit(patent);
Spring lock;
Blue Zinc Moungting Profiles,free of static.

Material:
SPCC cold rolled steel;
Thickness:mounting profile 2.0mm
mounting angle 1.5mm, others 1.2mm
Surface finish
Degreasing,phoshporic,powder coated.
Degree of protection:
Ip20.
Loading capacity
Static loading:800KG(with adjustable feet)
