Standard:

Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、
DIN41494;PART7,ETSI standard.

Feature:
Exquisite design with precise dimension and craftsmanship;
Toughened glass door with silk-screened flower pattern, vented front
door border and rear door;
Blue Zinc Moungting Profiles,free of static;
Adjustable feet and heavy duty castors are available simultaneously;
Cable entry on the top cover and bottom panel with adjustable sizes;
Optional installation of plinth to enable cabinets fixation; under-base
cable entry/ventilation;
Efficient and reliable cabinet connection by baying kit;
Removable side panels for easy maintenance;

Around 1/3 assembled original volume when flat pack.

Patent: NOZL 01353642.7

Material:
SPCC cold rolled steel;
Thickness:mounting profile 2.0mm
mouting angle 1.5mm,others 1.2mm

Surface finish
Degreasing,phosphoric,powder coated.

Degree of Protection:
Ip20.

Loading capacity
Static loading:800KG(with adjustable feet).
